Modicon Quantum Migration Solution

Modicon Quantum Migration Solution

Benefits:

  • Keep your existing field terminations landed. No ring out needed!
  • Perform your DCS conversion in hours instead of weeks.
  • All components are plug-and-play with keyed connectors
    to eliminate any chance of wiring errors.

To Technical Data

Step-by-Step Instructions

Please click on the images below to view the migration steps.

Start

Existing Modicon Quantum

Step 1

Remove existing Field Wiring adapters

Step 2

Remove existing controller cards

Step 3

Replace controller card with Weidmüller adapter card

Step 4

Reattach existing Field Wiring adapters

Step 5

Connect cable with connectors to adapter card

Finished

Completed and migrated DCS system

Download

Download: Migration Schneider Modicon — This Weidmuller brochure outlines a universal migration platform for Schneider Electric Modicon Quantum DCS systems, enabling upgrades without disturbing existing field wiring. It features plug‑and‑play card adapters, 40‑point conversion modules, and engineered cable harnesses to support fast system conversion in hours instead of weeks while reducing wiring effort and migration risk.
